Carbide Milling Tools | Indexable Milling Inserts
Kingdon Carbide Milling Tools are indexable inserts built for intermittent-cut regimes-face milling, 90° shoulder milling, slotting, ramping, contour profiling and high-feed roughing on CNC machining centers, knee mills and boring-mill conversions. Milling is not turning: every edge strikes and leaves the work cyclically, so the insert lives or dies on impact toughness, flank-heat management and pocket-seat repeatability. Our milling line uses fine- to medium-grain WC substrates with PVD TiAlN/TiCN (steel & stainless) or CVD Al₂O₃-based (cast iron) coatings, precision ground to ISO 3365 / ISO 1832 insert tolerances.
Covered geometries: APMT (positive 90° shoulder, 4-edge), RPKW / XNMP (positive square/rhombic, face & profile), WNEX / NWEX-style wavy (high-feed end milling), SNC (button/round-edge high-feed), LNE (linear high-feed double-sided). All fit standard global cutter bodies (Kennametal-, Iscar-, Sandvik-pocket equivalents).
Why Milling Inserts Are Specified Differently
Cyclic impact > steady wear: edge hone + T-land tuned per grade to stop micro-chipping at entry/exit, especially in stainless and alloy steel.
- Multiple usable edges: APMT gives 4 corners, double-sided square gives 8, SNC/LNE give 2–4 robust edges-cost-per-edge is the buyer's real unit, not cost-per-insert.
- Cutter-body synergy: same insert code behaves differently in 90° shell mill vs 20° high-feed cutter; ZZKD quotes insert + recommended lead angle + DOC window, not isolated SKU.
- Chip evacuation under flood or dry: positive rake + open chip chamber prevents nested "bird-nest" chips in slotting and deep shoulder passes.
- Material-driven grade map: P/M-class PVD for steel, M-class PVD for 304/316/17-4PH, K-class CVD for gray/ductile iron, N-polished uncoated for Al/Cu/Brass.
Typical Applications
Mold base face & cavity roughing, machine-tool slideways, hydraulic manifolds, flange facing, gearbox housings, brake disc rotor surfaces, pipe-end facing, aerospace bracket profiling, batch parts on twin-column VMCs. Wet or dry, high-rpm or low-rpm rigid setups.
|
Type |
Dimensions(mm) |
|||
|
ØI.C |
T |
Фd |
Re |
|
|
APMT1135PDER-K |
6.20 |
3.50 |
2.80 |
0.8 |
|
APMT1604PDER-K |
9.30 |
4.76 |
4.40 |
0.8 |
|
Type |
Dimensions(mm) |
|||
|
ØI.C |
T |
Фd |
Re |
|
|
RPKW1003MO-K |
10.00 |
3.18 |
4.40 |
11 |
|
RPKW1204MO-K |
12.00 |
4.76 |
4.40 |
11 |
|
RPMT10T3MO-K |
10.00 |
3.97 |
4.40 |
11 |
|
RPMT1204MO-K |
12.00 |
4.76 |
4.40 |
11 |
|
RDKW10T3MO-K |
10.00 |
3.97 |
4.40 |
15 |
|
RDKW1204MO-K |
12.00 |
4.76 |
4.40 |
15 |
|
RDMT1003MOTN |
10.00 |
3.18 |
4.40 |
15 |
|
RDMT1204MOTN |
12.00 |
4.76 |
4.40 |
15 |
|
Type |
Dimensions(mm) |
|||
|
ØI.C |
T |
Фd |
Re |
|
|
XPKT100404R-M |
6.90 |
4.00 |
3.80 |
0.4 |
|
XPKT150508R-M |
10.70 |
5.00 |
4.40 |
0.8 |
|
XPKT190608R-M |
13.50 |
6.00 |
5.10 |
0.8 |
|
Type |
Dimensions(mm) |
|||
|
ØI.C |
T |
Фd |
Re |
|
|
XNMP0603R-KM |
6.40 |
3.75 |
3.20 |
\ |
|
XNMP0904R-KM |
9.18 |
4.80 |
4.50 |
|
|
XNMP1205R-KM |
12.00 |
5.16 |
4.60 |
1.2 |
|
XNMP1306R-KM |
12.30 |
6.14 |
5.50 |
1.2 |
|
Type |
Dimensions(mm) |
|||
|
ØI.C |
T |
Фd |
Re |
|
|
WNMU080608EN-GM |
14.00 |
8.30 |
6.35 |
0.8 |
|
WNEX080608K-XF |
12.50 |
6.40 |
4.70 |
0.8 |
|
WNEX080608K-XT |
12.50 |
6.40 |
4.70 |
0.8 |
|
WNEX080608K-XM |
12.50 |
6.40 |
4.70 |
0.8 |
|
WNEX080616K-XF |
12.50 |
6.40 |
4.70 |
1.6 |
|
WNEX080616K-XT |
12.50 |
6.40 |
4.70 |
1.6 |
|
WNEX080616K-XM |
12.50 |
6.40 |
4.70 |
1.6 |
|
WOGU060408R-M |
9.20 |
4.65 |
3.70 |
0.8 |
|
WOGU090508R-M |
12.90 |
6.55 |
5.16 |
0.8 |
|
Type |
Dimensions(mm) |
|||
|
ØI.C |
T |
Фd |
Re |
|
|
LNMU0303EN-GM |
6.0 |
4.3 |
2.9 |
1.2 |
|
Type |
Dimensions(mm) |
|||||
|
L |
W |
S |
Фd |
α |
R |
|
|
(B)SNC33-DRO |
9.525 |
9.53 |
4.76 |
4.4 |
90 |
0 |
|
(A)SNC 33-DR10 |
9.525 |
9.53 |
4.76 |
4.4 |
90 |
10 |
|
(A)SNC33-DR11 |
9.525 |
9.53 |
4.76 |
4.4 |
90 |
11 |
|
(A)SNC 33-DR15 |
9.525 |
9.53 |
4.76 |
4.4 |
90 |
15 |
|
(A)SNC 33-DR20 |
9.525 |
9.53 |
4.76 |
4.4 |
90 |
20 |
|
(B)SNC 44-DRO |
12.70 |
12.70 |
7.94 |
5.4 |
90 |
0 |
|
(A)SNC 44-DR15 |
12.70 |
12.70 |
7.94 |
5.4 |
90 |
15 |
|
(A)SNC 44-DR20 |
12.70 |
12.70 |
7.94 |
5.4 |
90 |
20 |
|
(A)SNC 44-DR40 |
12.70 |
12.70 |
7.94 |
5.4 |
90 |
40 |
|
(B)SNC 55-DRO |
15.90 |
15.90 |
7.94 |
5.4 |
90 |
0 |
|
(A)SNC 55-DR13 |
15.90 |
15.90 |
7.94 |
5.4 |
90 |
13 |
|
A)SNC 55-DR14 |
15.90 |
15.90 |
7.94 |
5.4 |
90 |
14 |
|
A)SNC 55-DR23.5 |
15.90 |
15.90 |
7.94 |
5.4 |
90 |
23.5 |
|
B)LNE 313-DR0-6.35 |
12.70 |
9.53 |
6.35 |
4.5 |
90 |
0 |
|
A)LNE 313-DR10-6.35 |
12.70 |
9.53 |
6.35 |
4.5 |
90 |
10 |
|
A)LNE 313-DR11-6.35 |
12.70 |
9.53 |
6.35 |
4.5 |
90 |
11 |
|
A)LNE 313-DR15-6.35 |
12.70 |
9.53 |
6.35 |
4.5 |
90 |
15 |
|
A)LNE 313-DR20-6.35 |
12.70 |
9.53 |
6.35 |
4.5 |
90 |
20 |
|
B)LNE 313-DR0-5.56 |
12.70 |
9.53 |
5.56 |
4.5 |
90 |
0 |
|
A)LNE 313-DR10-5.56 |
12.70 |
9.53 |
5.56 |
4.5 |
90 |
10 |
|
A)LNE 313-DR11-5.56 |
12.70 |
9.53 |
5.56 |
4.5 |
90 |
11 |
|
A)LNE 313-DR15-5.56 |
12.70 |
9.53 |
5.56 |
4.5 |
90 |
15 |
|
A)LNE 313-DR20-5.56 |
12.70 |
9.53 |
5.56 |
4.5 |
90 |
20 |
|
B)LNE 323-DRO |
15.88 |
9.53 |
5.56 |
4.5 |
90 |
0 |
|
( A)LNE 323-DR10 |
15.88 |
9.53 |
5.56 |
4.5 |
90 |
10 |
|
A)LNE 323-DR11 |
15.88 |
9.53 |
5.56 |
4.5 |
90 |
11 |
|
( A)LNE 323-DR15 |
15.88 |
9.53 |
5.56 |
4.5 |
90 |
15 |
|
Type |
Dimensions(mm) |
|||||
|
L |
W |
S |
Фd |
α |
R |
|
|
(A)LNE 323-DR20 |
15.88 |
9.53 |
5.56 |
4.5 |
90 |
20 |
|
(B)LNE 424-DRO |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
0 |
|
(A)LNE 424-DR10 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
10 |
|
(A)LNE 424-DR11.5 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
11.5 |
|
(A)LNE 424-DR13 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
13 |
|
(A)LNE 424-DR14.5 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
14.5 |
|
(A)LNE 424-DR15.2 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
15.2 |
|
(A)LNE 424-DR16 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
16 |
|
(A)LNE 424-DR19 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
19 |
|
(A)LNE 424-DR20 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
20 |
|
(A)LNE 424-DR25 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
25 |
|
(A)LNE 424-DR40 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
40 |
|
(A)LNE 424-DR80 |
15.88 |
12.70 |
7.94 |
5.6 |
90 |
80 |
|
(B)LNE 434-DRO-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
0 |
|
(A)LNE 434-DR10-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
10 |
|
(A)LNE 434-DR11-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
11 |
|
(A)LNE 434-DR15-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
15 |
|
(A)LNE 434-DR20-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
20 |
|
(A)LNE 434-DR25-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
25 |
|
(A)LNE 434-DR30-6.35 |
19.05 |
14.30 |
6.35 |
5.6 |
90 |
30 |
|
(B)LNE 434-DRO-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
0 |
|
A)LNE 434-DR10-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
10 |
|
A)LNE 434-DR10-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
11 |
|
A)LNE 434-DR10-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
15 |
|
A)LNE 434-DR10-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
20 |
|
A)LNE 434-DR10-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
25 |
|
A)LNE 434-DR10-7.94 |
19.05 |
14.30 |
7.94 |
5.6 |
90 |
30 |
ZZKD B2B Supply Terms
Substrate blending → press → sinter → PVD/CVD → grind → edge-prep all in Zhuzhou; batch geometry checked, not trading-mixed stock.
- Grade recommendation by cutter type + material + DOC, not just ISO code: tell us APMT1604 in 90° shell mill, 45# steel, 2 mm DOC → we return grade + chipbreaker + speed/feed starting point.
- OEM/ODM: laser mark, neutral box or private label, mixed-series starter kit (APMT+RPKW+SNC) for distributor shelf.
- Free 6-piece sample set (2 grades × 3 geometries) for VMC test; FOB Zhuzhou/Shanghai, repeat-lot lead time quoted with MOQ.
- Inquiry format: cutter type / insert ISO / workpiece / DOC×ae×vf / coolant → code + grade + sample plan in 2 working days.
